1.0 Engine

(1) Brand/Model:

Yunnei YN38GBZ

(2) Type:

In-line arrangement, water-cooled, four cylinder, turbocharged diesel engine

(3) Rated Power:

76KW

(4) Optional Model:

EPA3 YANMAR engine;EPA3

EPA4/Euro4 HATZ engine;EPA4

EPA4 KOHLER engine;EPA4

CUMMINS 74.5KW engine;

YUCHAI 78KW engine

2.0 Overall Dimensions

(1) Overall Length:

7100mm

(2) Overall Width:

2100mm

(3) Overall Height:

3000mm

(4) Bucket hinge pin Height:

5300mm

(5)Telescopic stroke

1330mm

(6)Extend the arm length

3400mm

(7) Bucket Max.lift height

6100mm

(8) Bucket Max.unloading height

4500mm

3.0 Transmission System：

Gearbox+Hydraulic converter + Drive shaft + Hub reduction axle

4.0 Bucket：

(1) Capacity:

1.3m³

(2) Width:

2100mm

(3) Type:

Heavy-duty bolt on teeth

(5) Max. Load:

2500kg including bucket or attachment

5.0 Operating Specifications

(1) Steering System:

Articulated hydraulic steering

(2) Driving System:

Four wheel drive

(3) Hydraulic quick release

Yes

(4) Mechanical pilot joystick

Yes

(5) Steady rise

Yes

6.0 Brake System

(1) Service Brake:

Four wheel disc brake

(2) Parking Brake:

Disc brake

7.0 Tyre

(1) Model:

16/70-24 Herringbone Tyre

(2) Size:

Width: 410mm     Diameter: 1175mm

8.0 Wheel base: 2800mm

9.0 Track: 1700mm

10.System pressure:

20Mpa

11. Weight:

6800KG
