1.0 Engine

(1) Brand/Model:

Yuchai YCD4J22T-115

(2) Type:

In-line arrangement, water-cooled, four cylinder, turbocharged diesel engine

(3) Rated Power:

85KW

(4) Optional Model:

CUMMINS 74.5KW engine;

2.0 Overall Dimensions

(1) Overall Length:

7200mm

(2) Overall Width:

2200mm

(3) Overall Height:

3100mm

(4) Bucket hinge pin Height:

5400mm

(5)Telescopic stroke:

1330mm

(6)Extend the arm length:

3400mm

(7) Bucket Max.lift height:

6200mm

(8) Bucket Max.unloading height:

4600mm

3.0 Transmission System：

Gearbox+Hydraulic converter + Drive shaft + Hub reduction axle

4.0 Bucket：

(1) Capacity:

1.5m³

(2) Width:

2200mm

(3) Type:

Heavy-duty bolt on teeth

(5) Max. Load:

3000kg including bucket or attachment

5.0 Operating Specifications

(1) Steering System:

Articulated hydraulic steering

(2) Driving System:

Four wheel drive

(3) Hydraulic quick release

Yes

(4) Mechanical pilot joystick

Yes

(5) Steady rise

Yes

6.0 Brake System

(1) Service Brake:

Four wheel disc brake

(2) Parking Brake:

Disc brake

7.0 Tyre

(1) Model:

17.5-25 Herringbone Tyre

(2) Size:

Width: 440mm    Diameter: 1280mm

8.0 Wheel base: 2800mm

9.0 Track: 1750mm

10.System pressure:

20Mpa

11. Weight:

7000KG
