1.0 Engine

(1) Brand/Model:

Yuchai YC6B125-T20

(2) Type:

In-line arrangement, water-cooled, six cylinder，turbocharged diesel engine

(3) Rated Power:

92KW

(4) Optional Model:

CUMMINS 97KW engine;

WEICHAI 92KW engine;

2.0 Overall Dimensions

(1) Overall Length:

7500mm

(2) Overall Width:

2280mm

(3) Overall Height:

3200mm

(4) Bucket hinge pin Height:

6000mm

(5)Telescopic stroke

1530mm

(6)Extend the arm length

3800mm

(7) Bucket Max.lift height

6500mm

(8) Bucket Max.unloading height

5200mm

3.0 Transmission System：

Gearbox+Hydraulic converter + Drive shaft +28 Hub reduction axle

4.0 Bucket：

(1) Capacity:

1.7m³

(2) Width:

2280mm

(3) Type:

Heavy-duty bolt on teeth

(5) Max. Load:

3500kg including bucket or attachment

5.0 Operating Specifications

(1) Steering System:

Articulated hydraulic steering

(2) Driving System:

Four wheel drive

(3) Hydraulic quick release

Yes

(4) Hydraulic pilot joystick

Yes

(5) Steady rise

Yes

6.0 Brake System

(1) Service Brake:

Four wheel disc brake

(2) Parking Brake:

Disc brake

7.0 Tyre

(1) Model:

17.5-25 Herringbone Tyre

(2) Size:

Width: 440mm     Diameter: 1280mm

8.0 Wheel base: 2800mm

9.0 Track: 1750mm

10.System pressure:

20Mpa

11. Weight:

7800KG
