(1) Model:

YUNNEI YN27GBZ Turbo(Option Euro5 or EPA4 Engine)

  (2) Engine Type:

In-line arrangement,water-cooled,four-cycle diesel engine

  (3) Rated Power:

58KW

  (4) Rated Speed:

2400 r/min(rpm)

2.0 Transmission System

  (1) Type:

Fixed-spindle power shift

  (2) Shift gear control oil pressure

1.2-1.5 MPa

  (3) Rated input speed:

2500(rpm)

3.0 Bucket

  (1) Bucket capacity:

0.8m3

  (2) Bucket Width:

2000mm

  (3) Bucket type:

Heavy-duty bolt on teeth

  (4) Max.Breakout Force:

36.8KN

  (5) Rated load:

1800kg

  (6)Operating Weight

4600kg

4.0 Overall Dimensions

  (1) Overall length(bucket on ground)

5300mm

  (2) Overall Height(Ground to cab top):

2550mm

  (4) Dumping height:

2700mm

  (5) Min.base to the ground

275mm

  (6) Overall width

1800mm

5.0 Operating Specifications

  (1) Steering system:

Articulated frame with hydraulic power steering

  (2) Min.turning radius:

5200mm

  (3) Driving system:

Hydraulic converter

6.0 Brake System

  (1) Service Brake

Four wheel hydraulic spread-shoe brake

  (2) Parking Brake

Hand operated

7.0 Tyre

  (1) Standard Tyre

23.5/70-16

8.0 Wheelbase

1520mm

9.0 Track:

1500mm
