overall weight

5200kg

rated bucket capacity

1m3

maximum tractive force

≥54KN

maximum breakout force

≥45.4KN

maximum grade ability

30℃

maximum dump height

2850mm

Optional maximum dump height

3300mm

maximum dump reach

752mm

overall dimension (L×W×H)

5633×2000×2800mm

minimum turning radius

5300mm

Engine

model

Cummins EPA4

optional model

YUNNEI、YTO/YUCHAI/CUMMINS/YANMAR/KOHLER engine

type

Vertical, in-line, water cooled, 4-stroke diesel engine

rated power

55kw

Transmission system

gearbox mode

Countershaft power-shift

gear shift

4 forward shift 4 reverse shift

maximum speed

38km/h

Drive axles

 main reducing mode

Circular Arc Bevel gear, single stage

decelerating mode

Single stage planetary type

wheel base

2400mm

wheel tread

1640mm

ground clearance

310mm

Hydraulic system

 system working pressure

16MPa

boom lifting time

4.8s±0.2s

total time

9.2s±0.5s

fuel tank capacity

80L

function of leveling automatically

yes

Brake system

 service brake

air assist disc brake on 4 wheels

 parking brake

disc brake

Tyre

type model

16/70-20

front tyre pressure

0.22Mpa

rear tyre pressure

0.18Mpa

Package

1 unit packed into 20GP,2 units packed into 40HQ.

Warranty

12 months after delivery or 1500 work hours(whichever comes first)

Delivery time

15-25 days after 30% down payment.
