Overall weight

6200kg

Rated bucket capacity

1.4m³

Maximum tractive force

≥54KN

Maximum breakout force

≥45.4KN

Maximum grade ability

30°

Maximum dump height

3500mm

Overall dimension (L×W×H)

5890×2170×2850mm

Minimum turning radius

5330mm

Engine

Model

YUCHAII turbocharged engine

Optional model

CUMMINS 75KW engine

Type

Vertical, in-line, water cooled, 4-stroke diesel engine

Rated power

85KW

Engine starting mode

Electric

Transmission system

Torque converter

YJ280

Gearbox mode

Counter shaft power-shift

Gear shift

4 forward shift 4 reverse shift

Maximum speed

33km/h

Drive axles

Main reducing spiral

Circular Arc Bevel gear, single stage

Decelerating mode

Single stage planetary type

Wheel base (mm)

2400mm

Wheel tread

1640mm

Ground clearance

310mm

Driving mode

Four-wheel full hydraulic drive

Tire

Tire type

16/70-24 tire

Brake

Brake mode

Air assist disc brake on 4 wheels

Packaging

Packaging details

1 unit packed into 20GP,2 units packed into 1*40HQ.

Port

Qingdao

Delivery time

15-25 days after 30% down payment.

Warranty

12 months after delivery or 1500 work hours(whichever comes first)
