overall weight

9600kg

rated bucket capacity

1.7-2.5m3

maximum tractive force

≥97KN

maximum breakout force

≥127KN

maximum grade ability

30℃

maximum dump height

3100mm

Optional maximum dump height

3300mm

maximum dump reach

1006mm

overall dimension (L×W×H)

6890×2430×3070mm

minimum turning radius

5097mm

Engine

model

YUCHAI YC6B125-T20

optional model

Deutz WP6G125E22/ CUMMINS engine

type

Vertical, in-line, water cooled, 4-stroke diesel engine

rated power

92kw

maximum torque

500N.m

min fuel-consume ratio

≤210g/kw.h

Transmission system

gearbox mode

Power shift normally engaged straight gear

gear shift

4 forward shift 2 reverse shift

maximum speed

40km/h

Drive axles

main reducing mode

Bevel gear grade lreduction

decelerating mode

Bevel gear grade lreduction

wheel base

2660mm

wheel tread

1800mm

ground clearance

400mm

Hydraulic system

system working pressure

16.5MPa

boom lifting time

4.83s

total time

9.2s±0.5s

fuel tank capacity

156L

function of leveling automatically

yes

Brake system

service brake

air assist disc brake on 4 wheels

parking brake

Manual disk brake

Tyre

type model

17.5-25

front tyre pressure

0.4Mpa

rear tyre pressure

0.35Mpa
