2

overall weight

16500kg

3

rated bucket capacity

3m3

4

maximum tractive force

152KN

5

maximum breakout force

≥170KN

6

maximum grade ability

30℃

7

maximum dump height

3150mm

8

maximum dump reach

1250mm

9

overall dimension (L×W×H)

8085×2950×3450mm

10

minimum turning radius

6150mm

Engine

11

model

Weichai SteyrWD10G220E21

12

type

lnline  water cooling dry cylinder  injection

13

No. of cylinder-bore/stroke

6－126×130mm

14

rated power

162kw

15

maximum torque

980N.m

16

min fuel-consume ratio

≤215g/kw.h

Transmission system

17

torque converter

ZL50

18

gearbox mode

planetary

19

gear shift

2forward shift  1reverse shift

20

maximum speed

38km/h

Drive axles

21

main reducing spiral

bevel gear grade 1reduction

22

decelerating mode

planetary reduction,grade 1

23

wheel base (mm)

3250mm

24

wheel tread

2250mm

25

minimum ground clearance

460mm

 Hydraulic system

26

system working pressure

18Mpa

27

boom lifting time

5.95±0.2s

28

total time

10.95±0.5s

29

fuel tank capacity

290L

hydraulic oil tank capacity

250L

30

function of leveling automatically

有 yes

Brake system

31

service brake

air over hydraulic disc brake on 4 wheels

32

parking brake

manual parking brake

Tyre

33

type specification

23.5-25

34

front tyre pressure

0.4Mpa

35

rear tyre pressure

0.35Mpa
