2

overall weight

19800KG

3

rated bucket capacity

3.3m3

3

maximum tractive force

158KN

4

maximum breakout force

204KN

5

overall dimension (L×W×H)

8250×3100×3400mm

6

maximum grade ability

30℃

7

maximum dump height

3350mm

8

maximum dump reach

1255mm

9

minimum turning radius

6500mm

Engine

11

model

Weichai Steyr WD10G240E21

12

type

lnline  water cooling dry cylinder  injection

13

No. of cylinder-bore/stroke

6－126×130mm

14

rated power

175kw--2200r/min

15

maximum torque

843N.m

16

min fuel-consume ratio

≤220g/kw.h

Transmission system

17

torque converter

ＹＪ375

18

gearbox mode

Power shift normally engaged straight gear

19

gear shift

4 forward shift

4 reverse shift

20

maximum speed

38km/h

Drive axles

21

main reducing spiral

bevel gear grade 1reduction

22

decelerating mode

planetary reduction,grade 1

23

wheel base (mm)

3350mm

24

wheel tread

2250mm

25

minimum ground clearance

450mm

Hydraulic system

26

system working pressure

18MPa

27

boom lifting time

6.15+0.25s

28

total time

10.65+0.5s

29

fuel tank capacity

300L

30

function of leveling automatically

yes

Brake system

31

service brake

air over hydraulic disc brake on 4 wheels

32

parking brake

manual parking brake

Tyre

33

type specification

26.5-25

34

front tyre pressure

0.4Mpa

35

rear tyre pressure

0.35Mpa
