(1) Model:

FEV engine YN38GBZ

(2) Engine Type:

In-line arrangement,water-cooled, diesel engine

(3) Rated Power:

76KW

(4) Rated Speed:

2400 r/min(rpm)

(5) Optional:

2.0 Transmission System

  (1) Type:

Fixed-spindle power shift

  (2) Shift gear control oil pressure

1.2-1.5 MPa

  (3) Rated input speed:

2400(rpm)

3.0 Bucket

  (1) Bucket capacity:

1.2m3

  (2) Bucket Width:

2000mm

  (3) Bucket type:

Heavy-duty bolt on teeth

  (4) Rated load:

2000kg

  (5)Operating Weight

5000kg

4.0 Overall Dimensions

  (1) Overall length(bucket on ground)

6100mm

  (2) Overall Height(Ground to cab top)

2850mm

  (3) Dumping height:

3500mm

  (4) Min.base to the ground

240mm

  (5) Overall width

2060mm

5.0 Operating Specifications

  (1) Steering system:

Articulated frame with hydraulic power steering

  (2) Min.turning radius:

4200mm

  (3) Driving system:

Hydraulic converter

6.0 Brake System

  (1) Service Brake

Four wheel Disc- brake

  (2) Parking Brake

Hand operated

7.0 Tyre

 (1)Standard Tyre

16/70-20 Tyre

 (2)Optional Tyre

 Tyre
